Mobile loading ramp is an auxiliary device used to help forklifts load and unload goods between the ground and vehicles or loading and unloading platforms at different heights. It adjusts the height through a hydraulic system, allowing forklifts to drive directly into the compartment for batch loading and unloading. No external power supply is required and only one person is required to complete the operation.
The mobile dock leveler mainly relies on the hydraulic system to achieve lifting and height adjustment, so that the forklift can directly enter the interior of the vehicle for loading and unloading operations. Its working principle is that the hydraulic oil generates pressure through the vane pump, enters the hydraulic cylinder after passing through a series of valves, and pushes the piston upward, thereby raising the platform height of the dock leveler. When descending, the hydraulic oil flows in the opposite direction, and is controlled by the balance valve and hydraulically controlled one-way valve to achieve smooth descent and safe braking.
The mobile boarding bridge can easily adjust the height of the bridge plate through a hydraulic system or a manual hydraulic pump, so that it is consistent with the height of the carriage under different vehicle models and loading and unloading conditions, ensuring that the forklift can enter the carriage smoothly.
The platform of the mobile boarding bridge is made of high-strength steel plate diamond grid plate or hollow steel grid plate and other materials. The chassis is supported by a solid main beam and secondary beam, with sufficient strength and carrying capacity to withstand the weight of the forklift and cargo, ensuring the stability and safety of the loading and unloading process.
The platform of the mobile boarding bridge usually adopts an anti-slip design, such as a diamond grid plate, a hollow steel grid, etc., to ensure that the forklift has a good grip when going up and down the ramp to prevent slipping.
The mobile boarding bridge is usually equipped with safety devices such as tire blocking blocks, trailer chains, and supporting hand-cranked legs to ensure the safety of the loading and unloading process.
Solve the loading and unloading problems between vehicles of different heights and warehouse platforms, and improve the efficiency of cargo turnover.
Facilitate the loading and unloading of cargo between containers and the ground.
Cooperate with forklifts to load and unload large quantities of cargods, improving warehousing efficiency.
Mobility and convenience:
The mobile loading ramp adopts a wheeled design, which is easy to move to different loading and unloading locations. It does not require fixed installation and is suitable for loading and unloading places with strong mobility.
Single-person operation:
Mobile loading ramps are usually designed for single-person operation, without additional manpower, which improves loading and unloading efficiency.
No power supply required:
Most mobile loading ramps are driven by manual hydraulics and do not require external power supply, which is convenient for use in various environments.
In short, the core function of the mobile loading ramp is to provide an adjustable height, safe, reliable, convenient and efficient loading and unloading channel to solve the loading and unloading problems of vehicles of different heights and improve logistics efficiency.
